KN-260

Providing maximum versatility in a compact, established platform. Suitable for all ranges of thermoforming applications, the KN260 offers excellent price-performance.

  • Compact “cabinet” style frame with accessibility across the machine width
  • All main movement groups operated by servo motors
  • Positioning sensors at each cycle guarantees the correct alignment of the sealing and cutting stations with the profile of the blister
  • Positive control of all product loading processes
  • Industry leading sealing technology ensures uniformity and quality of lid sealing process
  • Suitable for use with sustainable Recycled PET Forming and Lidding materials
  • Thermoforming and Coldforming capabilities (with upgrade)
Performance Max.
  • 30 forming cycles/minute

  • Variable according to product, material, and format size

Forming material
  • PVC, PET, rPET, PS, and other thermoforming materials

  • Aluminum cold forming

Lidding material
  • Al, paper/Al, polyester/Al, PP, Tyvek

Forming technology
  • Mold and Counter-Mold with integrated vacuum

Sealing technology
  • Platen

Max. forming area
  • 260 mm (web width) x 260 mm (pitch)

Max. forming depth
  • 40 mm

Frame
  • Aluminum

Max. reel diameter
  • 600 mm forming material

  • 300 mm lidding material

  • 74 – 78 mm core inner diameter
